MA2506 Series
Manufacturer: Mechatronics Fan Group
Beta
⌘K
FAN AXIAL 25X6.1MM 12VDC WIRE
| Part | Current Rating (Amps) | Voltage - Rated | Voltage Range [Max] | Voltage Range [Min] | Material - Blade | Termination | Bearing Type | Noise | Fan Type | Approval Agency | Width | Static Pressure | Static Pressure | RPM | Weight | Weight | Features | Size / Dimension [x] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mechatronics Fan Group | 60 mA | 5 V 12 VDC | 13 V | 6 VDC | Polybutylene Terephthalate (PBT) | 2 Wire Leads | 1 Ball 1 Sleeve | 19 dB(A) | Tubeaxial | cUL TUV UL | 6.1 mm | 0.09 in H2O | 22.4 Pa | 8500 RPM | 8.16 g | 0.018 lb | Thermal Overload Protector (TOP) | 25 mm | 25 mm |
