GP100H3 Series
Manufacturer: OmniOn Power™
Beta
⌘K
AC/DC CONVERTER 52V 6000W
| Part | Current - Output 1 | Power (Watts) | Voltage - Input [Min] | Voltage - Input [Max] | Features | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Applications | Type | Number of Outputs | Voltage - Isolation | Voltage - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Efficiency | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OmniOn Power™ | 111.1 A | 6000 W | 320 VAC | 530 VAC | 80 Plus® Titanium Adjustable Output I2C Interface Load Sharing PFC PMBus™ Remote Sense Standby Output Universal Input | 445.3 mm | 7.98 in | 17.53 in | 202.5 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 52 V | 75 ░C | -10 °C | 92 % | Rack Mount | |
 OmniOn Power™ | 125 A | 6000 W | 320 VAC | 530 VAC | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Standby Output | 440.9 mm | 7.97 " | 17.36 in | 202.4 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 48 V | 75 ░C | -10 °C | 96 % | Rack Mount | CE |
 OmniOn Power™ | 111 A | 6000 W | 320 VAC | 530 VAC | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Standby Output | 445.3 mm | 7.97 " | 17.53 in | 202.4 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 54 V | 75 ░C | -10 °C | 96 % | Rack Mount | CE |
OmniOn Power™ | 111 A | 6000 W | 320 VAC | 530 VAC | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Standby Output | 445.3 mm | 7.97 " | 17.53 in | 202.4 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 54 V | 75 ░C | -10 °C | 96 % | Rack Mount | CE |
OmniOn Power™ | 125 A | 6000 W | 320 VAC | 530 VAC | Adjustable Output Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote On/Off Standby Output | 440.9 mm | 7.97 " | 17.36 in | 202.4 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 48 V | 75 ░C | -10 °C | 96 % | Rack Mount | CE |
OmniOn Power™ | 111.1 A | 6000 W | 320 VAC | 530 VAC | 80 Plus® Titanium Adjustable Output I2C Interface Load Sharing PFC PMBus™ Remote Sense Standby Output Universal Input | 445.3 mm | 7.98 in | 17.53 in | 202.5 mm | 1.61 " | 40.9 mm | ITE (Commercial) | Front End | 1 | 3000 V | 52 V | 75 ░C | -10 °C | 92 % | Rack Mount |
