VK162 Series

Catalog

DISPLAY VACUUM FLORESCENT 4X20

Part	Display Format [x]	Display Format [y]	Viewing Area [y]	Viewing Area [x]	Operating Temperature [Min]	Operating Temperature [Max]	Outline L x W x H [x]	Outline L x W x H [z]	Outline L x W x H [y]	Character Size [z]	Character Size [y]	Interface	Display Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Format [y]	Format	Format [x]
Matrix Orbital VK162-12-USB	16	2	11.4 mm	51.4 mm	-20 ░C	70 °C	80 mm	27.67 mm	36 mm	2.28 mm	4.76 mm	I2C USB	Character
Matrix Orbital VK162-12-V-E	16	2	11.4 mm	51.4 mm	-40 C	85 °C	80 mm	27.67 mm	36 mm	2.28 mm	4.76 mm	I2C	Character	15 V	9 V
Matrix Orbital VK162-12-USB-E
Matrix Orbital VK162-12	16	2	11.4 mm	51.4 mm	-20 ░C	70 °C	80 mm	12.7 mm	36 mm	4.76 mm	2.46 mm	Serial	Character			7	Dots	5 Dots
Matrix Orbital VK162-12-E	16	2	11.4 mm	51.4 mm	-40 C	85 °C	80 mm	12.7 mm	36 mm	4.76 mm	2.46 mm	Serial	Character			7	Dots	5 Dots
