895-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 29POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Finish | Color | Gender | Termination | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Card Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Read Out | Mounting Type | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 3.25 mm | 0.128 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 2.95 mm | 0.116 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 3.96 mm | 0.156 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Wire Wrap | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Wire Wrap | 3.25 mm | 0.128 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 2.95 mm | 0.116 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Right Angle Through Hole | Copper Alloy | Floating Bobbin Flush Mount |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 3.25 mm | 0.128 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Solder | 3.25 mm | 0.128 " | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Black | Female | Wire Wrap | 29 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 125 °C | -40 C | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | Single | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening |
