180-062 Series
Manufacturer: NorComp Inc.
Beta
⌘K
HD D SUB CONN, RCPT, 62POS, DC, SLDR CUP ROHS COMPLIANT: YES
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Dielectric Material | Current Rating (Amps) | Contact Finish | Shell Material, Finish | Number of Rows [custom] | Contact Finish Thickness | Contact Type | Material Flammability Rating | Number of Positions | Shell Size, Connector Layout | Shell Size, Connector Layout | Mounting Type | Flange Feature | Features | Connector Style | Connector Type | Note | Contact Form | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Color | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 5 A | Gold | Nickel Plated Steel | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount | 4-40 | Shielded | D-Sub High Density | Receptacle Female Sockets | ||||||
 NorComp Inc. | 100 °C | -50 °C | Nickel Plated Steel | 3 | Signal | 62 | C DC | 4 | Free Hanging (In-Line) | 4-40 | Grounding Indents | D-Sub High Density | Plug for Male Contacts | Contacts Not Included | |||||||||||
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 5 A | Gold | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount | Housing/Shell (Unthreaded) | Shielded | D-Sub High Density | Receptacle Female Sockets | Stamped | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 5 A | Gold | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount | 4-40 | Grounding Indents Shielded | D-Sub High Density | Plug Male Pins | |||||||
NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 5 A | Gold | Nickel Plated Steel | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount | Cable Side (4-40) | Shielded | D-Sub High Density | Receptacle Female Sockets | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polyester Glass Filled | 2 A | Gold | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount Through Hole | Board Side (4-40) | Grounding Indents | D-Sub High Density | Plug Male Pins | Black | Solder | ||||||
 NorComp Inc. | 100 °C | -50 °C | Nickel Plated Steel | 3 | Signal | 62 | C DC | 4 | Free Hanging (In-Line) | Cable Side (4-40) | D-Sub High Density | Receptacle for Female Contacts | Contacts Not Included | ||||||||||||
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 3 A | Gold | Nickel Plated Steel | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount Through Hole | Board Side (4-40) | Grounding Indents Shielded | D-Sub High Density | Plug Male Pins | Solder | |||||
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 5 A | Gold | Nickel Plated Steel | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount | Housing/Shell (Unthreaded) | Shielded | D-Sub High Density | Receptacle Female Sockets | ||||||
 NorComp Inc. | 100 °C | -50 °C | Brass | Polybutylene Terephthalate (PBT) | 3 A | Gold | Nickel Plated Steel | 3 | Flash | Signal | UL94 V-0 | 62 | C DC | 4 | Panel Mount Through Hole | Board Side (4-40) | Shielded | D-Sub High Density | Receptacle Female Sockets | Solder |
