SDE0403A Series

Catalog

POWER INDUCTOR (SMD), 12 ΜH, 1 A, UNSHIELDED, 1.3 A, SDE0403A SERIES

Part	Current Rating (Amps)	Package / Case	Type	Frequency - Self Resonant	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	DC Resistance (DCR) [Max]	Ratings	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Tolerance	Inductance	Shielding	Current - Saturation (Isat)	Material - Core	Inductance Frequency - Test	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]
Bourns Inc. SDE0403A-120M	1 A	Nonstandard	Drum Core Wirewound	32 MHz	125 °C	-40 C	Surface Mount	197 mOhm	AEC-Q200	0.138 "	3.5 mm	20 %	12 µH	Unshielded	1.3 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
Bourns Inc. SDE0403A-470K	0.5 A	Nonstandard	Drum Core Wirewound	16 MHz	125 °C	-40 C	Surface Mount		AEC-Q200	0.138 "	3.5 mm	10 %	47 µH	Unshielded	0.65 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
Bourns Inc. SDE0403A-180M	750 mA	Nonstandard	Drum Core Wirewound	28 MHz	125 °C	-40 C	Surface Mount	309 mOhm	AEC-Q200	0.138 "	3.5 mm	20 %	18 µH	Unshielded	1.1 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
Bourns Inc. SDE0403A-150M	0.85 A	Nonstandard	Drum Core Wirewound	29 MHz	125 °C	-40 C	Surface Mount	259 mOhm	AEC-Q200	0.138 "	3.5 mm	20 %	15 µH	Unshielded	1.2 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
Bourns Inc. SDE0403A-2R2M	2.3 A	Nonstandard	Drum Core Wirewound	76 MHz	125 °C	-40 C	Surface Mount	71 mOhm	AEC-Q200	0.138 "	3.5 mm	20 %	2.2 µH	Unshielded	3.3 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
Bourns Inc. SDE0403A-4R7M	1.65 A	Nonstandard	Drum Core Wirewound	50 MHz	125 °C	-40 C	Surface Mount	108 mOhm	AEC-Q200	0.138 "	3.5 mm	20 %	4.7 ÁH	Unshielded	2.2 A	Ferrite	1 MHz	0.157 "	0.177 in	4.5 mm	4 mm
