A3SA-90 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SQUARE DPDT ALT 5VDC GREEN
| Part | Electrical Life | Mechanical Life | Switch Function | Actuator Type | Type | Illumination Type, Color | Color - Actuator/Cap | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - DC | Circuit | Termination Style | Ingress Protection | Current Rating (Amps) | Mounting Type | Voltage Rating - AC | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Actuator Marking | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | ||||||||||||||||||||
Omron Automation and Safety | ||||||||||||||||||||
 Omron Automation and Safety | 100000 Cycles | 1000000 Cycles | On-Mom | Button Square | Illuminated Standard | Green LED | Green | 50 °C | -10 °C | 30 V | DPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
 Omron Automation and Safety | 100000 Cycles | 1000000 Cycles | On-Mom | Button Square | Illuminated Standard | Amber LED | White | 50 °C | -10 °C | 30 V | SPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
 Omron Automation and Safety | 100000 Cycles | 1000000 Cycles | On-Mom | Button Square | Illuminated Standard | LED White | White | 50 °C | -10 °C | 30 V | SPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
Omron Automation and Safety | ||||||||||||||||||||
 Omron Automation and Safety | 100000 Cycles | 100000 Cycles | On-On | Button Square | Illuminated Standard | Green LED | Green | 50 °C | -10 °C | 30 V | SPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
Omron Automation and Safety | ||||||||||||||||||||
 Omron Automation and Safety | 100000 Cycles | 1000000 Cycles | On-Mom | Button Square | Illuminated Standard | LED Orange | Orange | 50 °C | -10 °C | 30 V | SPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
 Omron Automation and Safety | 100000 Cycles | 100000 Cycles | On-On | Button Square | Illuminated Standard | LED White | White | 50 °C | -10 °C | 30 V | SPDT | Quick Connect - 0.110" (2.8mm) | IP00 | 2 A 3 A | Panel Mount Snap-In | 125 V | 16.2 mm | 16.2 mm | No Marking | 24 VAC/DC |
