325-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 34POS 0.100
| Part | Termination Rows | Material - Insulation | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness | Card Thickness | Gender | Contact Material | Termination | Card Type | Number of Positions [custom] | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Color | Mounting Type | Contact Finish | Number of Positions/Bay/Row | Contact Type | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Read Out | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | 3.18 mm | 0.125 in | Female | Copper Alloy | Solder | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | Female | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | Cantilever | 0.25 Ám | 10 Áin | Dual | 2 | 2 | 17 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | Female | Copper Alloy | Solder | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | Female | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Female | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | ||||||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | Female | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | 3.18 mm | 0.125 in | Female | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | Cantilever | 0.25 Ám | 10 Áin | Dual | 2 | 2 | 17 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | Female | Copper Alloy | Solder | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Female | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | Cantilever | 0.25 Ám | 10 Áin | Dual | 2 | 2 | 17 | ||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | 3.18 mm | 0.125 in | Female | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 34 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | Green | Through Hole | Gold | 34 | Cantilever | 1 | 0.25 Ám | 10 Áin | Single |
