Lexium 28 Series
Manufacturer: SCHNEIDER ELECTRIC
Beta
⌘K
AC, DC & SERVO MOTORS 80MM, 400W, IP65, W/ KEY, LEADS
| Part | Features | Termination Style | Mounting Hole Spacing [custom] | Mounting Hole Spacing [custom] | Power - Rated | Voltage - Rated | Function | Encoder Type | Diameter - Shaft [diameter] | Diameter - Shaft [diameter] | Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension | RPM | Length - Shaft and Bearing [x] | Length - Shaft and Bearing | Operating Temperature [Min] | Operating Temperature [Max] | Torque - Rated (oz-in / mNm) | Torque - Rated (oz-in / mNm) | Current - Output | Control / Drive Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Voltage - Load [Min] | Voltage - Load [Max] | Mounting Type | Interface | Motor Type | Wattage - Load | For Use With/Related Products | Length - Shaft and Bearing [x] | Length - Shaft and Bearing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHNEIDER ELECTRIC | Key | Cable with Connector | 70 mm | 2.756 in | 400 W | 220 VAC | Servomotor | Absolute | 0.55 in | 13.97 mm | AC Motor | 80 mm | 80 mm | 3.15 in | 3.15 " | Square | 5000 RPM | 1.18 in | 29.97 mm | -20 ░C | 40 °C | 179.8 oz-in | 1270 mNm | |||||||||||||
 SCHNEIDER ELECTRIC | Module | 4.5 A | Servo AC | 200 VAC | 240 VAC | 200 V | 240 V | Chassis Mount | EtherCAT RS-485 | Servo | 200 W | Lexium 28 Series | ||||||||||||||||||||||||
SCHNEIDER ELECTRIC | Brake Oil Seal | Cable with Connector | 70 mm | 2.756 in | 220 VAC | Servomotor | Absolute | 0.75 in | 19.05 mm | AC Motor | 80 mm | 80 mm | 3.15 in | 3.15 " | Square | 5000 RPM | 1.378 " | 0 °C | 40 °C | 338.5 oz-in | 2390 mNm | 35 mm | ||||||||||||||
 SCHNEIDER ELECTRIC | Brake Key Oil Seal | Connector | 114.3 mm | 4.5 in | 3 kW | 220 VAC | Servomotor | Absolute | 1.378 in | 35 mm | AC Motor | 180 mm | 180 mm | 7.087 " | 7.087 in | 3000 RPM | 79 mm | 0 °C | 40 °C | 2028 oz-in | 14320 mNm | 3.11 in | ||||||||||||||
SCHNEIDER ELECTRIC | Oil Seal | Cable with Connector | 70 mm | 2.756 in | 400 W | 220 VAC | Servomotor | Absolute | 0.55 in | 13.97 mm | AC Motor | 80 mm | 80 mm | 3.15 in | 3.15 " | Square | 5000 RPM | 1.18 in | 29.97 mm | -20 ░C | 40 °C | 179.8 oz-in | 1270 mNm | |||||||||||||
 SCHNEIDER ELECTRIC | Module | 7.8 A | Servo AC | 200 VAC | 240 VAC | 200 V | 240 V | Chassis Mount | CAN RS-485 | Servo | 400 W | Lexium 28 Series | ||||||||||||||||||||||||
 SCHNEIDER ELECTRIC | Module | 60 A | Servo AC | 200 VAC | 240 VAC | 200 V | 240 V | Chassis Mount | EtherCAT RS-485 | Servo | 3 kW | Lexium 28 Series | ||||||||||||||||||||||||
 SCHNEIDER ELECTRIC | Oil Seal | Connector | 50 mm | 1.969 in | 400 W | 220 VAC | Servomotor | Absolute | 0.55 in | 13.97 mm | AC Motor | 59.94 mm | 59.94 mm | 2.36 " | 2.36 " | Square | 5000 RPM | 1.18 in | 29.97 mm | -20 ░C | 40 °C | 179.8 oz-in | 1270 mNm | |||||||||||||
 SCHNEIDER ELECTRIC | Brake Oil Seal | Connector | 109.98 mm | 4.33 in | 600 W | 220 VAC | Servomotor | Absolute | 0.87 in | 22.1 mm | AC Motor | 130.05 mm | 130.05 mm | 5.12 " | 5.12 in | 3000 RPM | 1.772 in | 0 °C | 40 °C | 811.4 oz-in | 5730 mNm | 45 mm | ||||||||||||||
SCHNEIDER ELECTRIC | Brake Oil Seal | Connector | 114.3 mm | 4.5 in | 3.5 kW | 220 VAC | Servomotor | Absolute | 1.378 in | 35 mm | AC Motor | 180 mm | 180 mm | 7.087 " | 7.087 in | 3000 RPM | 79 mm | 0 °C | 40 °C | 2364.9 oz-in | 16700 mNm | 3.11 in |
