34414 Series

Catalog

HOOK-UP STRND 14AWG GRAY

Part	Length	Length	Ratings	Jacket Color	Voltage	Features	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Jacket (Insulation) Material	Wire Gauge	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Belden Inc. 34414 008500	152.4 m	500 ft	UL Style 3191	Gray	600 V	Oil Resistant	41	30	0.048 in	1.22 mm	-30 ░C	105 ░C	Copper Tinned	Chlorosulfonated Polyethylene (CSPE)	14.5 AWG	Hook-Up	0.17 in	4.32 mm
Belden Inc. 34414 010100			UL Style 3191	Black	600 V	Oil Resistant	41	30	0.048 in	1.22 mm	-30 ░C	105 ░C	Copper Tinned	Chlorosulfonated Polyethylene (CSPE)	14.5 AWG	Hook-Up	0.17 in	4.32 mm	100 ft	30.5 m
Belden Inc. 34414 010500	152.4 m	500 ft	UL Style 3191	Black	600 V	Oil Resistant	41	30	0.048 in	1.22 mm	-30 ░C	105 ░C	Copper Tinned	Chlorosulfonated Polyethylene (CSPE)	14.5 AWG	Hook-Up	0.17 in	4.32 mm
Belden Inc. 34414 005500	152.4 m	500 ft	UL Style 3191	Green	600 V	Oil Resistant	41	30	0.048 in	1.22 mm	-30 ░C	105 ░C	Copper Tinned	Chlorosulfonated Polyethylene (CSPE)	14.5 AWG	Hook-Up	0.17 in	4.32 mm
Belden Inc. 34414 002500	152.4 m	500 ft	UL Style 3191	Red	600 V	Oil Resistant	41	30	0.048 in	1.22 mm	-30 ░C	105 ░C	Copper Tinned	Chlorosulfonated Polyethylene (CSPE)	14.5 AWG	Hook-Up	0.17 in	4.32 mm
