681M13W Series
Manufacturer: NorComp Inc.
Beta
⌘K
COMBO D-SUB CONN, PLUG, DB-13W3, TH ROHS COMPLIANT: YES
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Color | Contact Material | Dielectric Material | Number of Positions [custom] | Number of Positions [custom] | Current Rating (Amps) | Material Flammability Rating | Contact Type | Flange Feature | Mounting Type | Connector Type | Termination | Number of Rows [custom] | Contact Finish Thickness | Contact Finish | Shell Material, Finish | Connector Style | Features | Shell Size, Connector Layout | Shell Size, Connector Layout | Current Rating (Amps) [Max] | Current Rating (Amps) [Min] | Voltage Rating | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 155 C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Plug Male Pins | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Grounding Indents | 3 | 13C3 13W3 | |||||||
 NorComp Inc. | 155 C | -55 C | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 3 A | UL94 V-0 | Signal and Power | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Receptacle Female Sockets | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | 3 | 13C3 13W3 | 40 A | 20 A | |||||||
 NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Board Side (4-40) | Panel Mount Through Hole | Plug Male Pins | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Board Lock Grounding Indents | 3 | 13C3 13W3 | 250 V | ||||||
 NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 5 A 40 A | UL94 V-0 | Signal and Power | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Receptacle Female Sockets | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | 13 | 4 | C DC | 13W6 | ||||||||
NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 5 A 40 A | UL94 V-0 | Signal and Power | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Plug Male Pins | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Grounding Indents | 13 | 4 | C DC | 13W6 | |||||||
 NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Board Side (4-40) | Panel Mount Through Hole | Receptacle Female Sockets | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Board Lock | 3 | 13C3 13W3 | 250 V | ||||||
NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Board Side (4-40) | Panel Mount Through Hole | Receptacle Female Sockets | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Board Lock | 3 | 13C3 13W3 | 250 V | ||||||
 NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Board Side (4-40) | Panel Mount Through Hole | Receptacle Female Sockets | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | 3 | 13C3 13W3 | 250 V | |||||||
 NorComp Inc. | 125 °C | -55 C | Black | Copper Alloy | Polybutylene Terephthalate (PBT) | 10 | 3 | 5 A 40 A | UL94 V-0 | Signal and Power | Board Side (4-40) | Panel Mount Through Hole | Plug Male Pins | Solder | 2 | Flash | Gold | Nickel Plated Steel | Combo D-Sub | Board Lock Grounding Indents | 3 | 13C3 13W3 |
