AXA016 Series

Catalog

DC DC CONVERTER 0.8-5.5V 88W

Part	Control Features	Power (Watts)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Voltage - Input (Max) [Max]	Type	Number of Outputs	Applications	Mounting Type	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1 [Min] [custom]	Voltage - Output 1 [Max] [custom]	Current - Output (Max) [Max]	Efficiency	Package / Case	Features
OmniOn Power™ AXA016A0X3-SRZ	Active Low Enable	88 W	33 mm	13.5 mm	0.53 in	1.3 in	0.33 in	8.3 mm	14 V	Non-Isolated PoL Module	1	ITE (Commercial)	Surface Mount	10 VDC	85 °C	-40 C	0.8 V	5.5 V	16 A	92 %	6-SMD Module	OCP OTP Remote On/Off UVLO
OmniOn Power™ AXA016A0X3-SRZ	Active Low Enable	88 W	33 mm	13.5 mm	0.53 in	1.3 in	0.33 in	8.3 mm	14 V	Non-Isolated PoL Module	1	ITE (Commercial)	Surface Mount	10 VDC	85 °C	-40 C	0.8 V	5.5 V	16 A	92 %	6-SMD Module	OCP OTP Remote On/Off UVLO
