PUR5C04 Series
Manufacturer: Panduit Corp
Beta
⌘K
COPPER CABLE, CATEGORY 5E, 4-PAIR, 24AWG
| Part | Conductor Material | Jacket (Insulation) Material | Conductor Strand | Jacket Color | Cable Type | Length | Length | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Conductor Insulation | Voltage | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | Copper Bare | Poly-Vinyl Chloride (PVC) | Solid | White | Multi-Pair Cat5e | 304.8 m | 1000 ft | 8 | 0.189 in | 4.8 mm | 24 AWG | Fluorinated Ethylene-Propylene (FEP) | 80 V | |
 Panduit Corp | Copper Bare | Poly-Vinyl Chloride (PVC) Riser | Solid | Red | Multi-Pair Cat5e | 304.8 m | 1000 ft | 8 | 0.187 in | 4.75 mm | 24 AWG | Polyolefin | 80 V | PO |
 Panduit Corp | Copper Bare | Poly-Vinyl Chloride (PVC) Riser | Solid | Gray | Multi-Pair Cat5e | 304.8 m | 1000 ft | 8 | 0.187 in | 4.75 mm | 24 AWG | Polyolefin | 80 V | PO |
 Panduit Corp | Copper Bare | Poly-Vinyl Chloride (PVC) | Solid | Blue | Multi-Pair Cat5e | 304.8 m | 1000 ft | 8 | 0.189 in | 4.8 mm | 24 AWG | Fluorinated Ethylene-Propylene (FEP) | 80 V |
