LDA100W Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
AC/DC CONVERTER 24V 103W
| Part | Voltage - Output 1 | Current - Output 1 | Approval Agency | Number of Outputs | Features | Voltage - Input [Min] | Voltage - Input [Max] | Mounting Type | Type | Efficiency | Applications | Power (Watts) | Voltage - Isolation | Standard Number | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | 24 V | 4.3 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Open Frame | 83 % | ITE (Commercial) | 103 W | 3000 V | 60950-1 | -10 °C | 60 °C | ||||||
Cosel USA, Inc. | 12 V | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | 81 % | ITE (Commercial) | 102 W | 3000 V | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm | |
Cosel USA, Inc. | 48 V | 2 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | ITE (Commercial) | 96 W | 3000 V | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm | |
Cosel USA, Inc. | 24 V | 4.3 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | 83 % | ITE (Commercial) | 103 W | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm | |
Cosel USA, Inc. | 24 V | 4.3 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | 83 % | ITE (Commercial) | 103 W | 3000 V | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm |
Cosel USA, Inc. | 24 V | 4.3 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Open Frame | 83 % | ITE (Commercial) | 103 W | 3000 V | 60950-1 | -10 °C | 60 °C | ||||||
Cosel USA, Inc. | 48 V | 2 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | ITE (Commercial) | 96 W | 3000 V | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm | |
Cosel USA, Inc. | 3 V | 20 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Enclosed | 75 % | ITE (Commercial) | 60 W | 3000 V | 60950-1 | -10 °C | 60 °C | 9.92 " | 2.83 " | 252 mm | 45 mm | 1.77 in | 72 mm |
Cosel USA, Inc. | 15 V | 6.7 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Open Frame | ITE (Commercial) | 101 W | 3000 V | 60950-1 | -10 °C | 60 °C | |||||||
Cosel USA, Inc. | 3 V | 20 A | cCSAus CE cURus TUV | 1 | Adjustable Output Universal Input | 85 VAC 170 VAC | 132 VAC 264 VAC | Chassis Mount | Open Frame | 75 % | ITE (Commercial) | 60 W | 3000 V | 60950-1 | -10 °C | 60 °C |
