78604 Series

Catalog

SMD TRANSFORMER 2:1 2000UH 20VUS ROHS COMPLIANT: YES

Part	Inductance	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Transformer Type	Operating Temperature [Max]	Turns Ratio - Primary:Secondary [custom]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	ET (Volt-Time)	Weight	Weight
Murata Electronics 78604/1MC	2 mH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	20 VµS
Murata Electronics 78604/2C	500 µH	Through Hole	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	10 VµS
Murata Electronics 78604/16C	4 mH	Through Hole	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	28 VµS
Murata Electronics 78604/9C	10 mH	Through Hole	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.375 in	9.52 mm	0.354 in	9 mm	56 VµS	1.14 g	0.04 oz
Murata Electronics 78604/3JC-R	160 µH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	6 VµS
Murata Electronics 78604/8MC-R	1 mH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	15 VµS
Murata Electronics 78604/3MC	200 µH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	6 VµS
Murata Electronics 78604/9MC	10 mH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	56 VµS
Murata Electronics 78604/4C	67 µH	Through Hole	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.375 in	9.52 mm	0.354 in	9 mm	4 VµS	1.14 g	0.04 oz
Murata Electronics 78604/1JC	1.84 mH	Surface Mount	6.35 mm	0.25 in	General Purpose	70 °C	2:1	0.354 in	9 mm	0.375 in	9.52 mm	20 VµS
