PX0105 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
AUTOMOTIVE CONNECTOR, A KEY, PX0 SERIES, STRAIGHT PLUG, 8 CONTACTS
| Part | Note | Color | Fastening Type | Connector Type | Mounting Type | Contact Termination | Contact Type | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Material | Features | Number of Positions | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Contacts Not Included | Black | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 8 | |
 BULGIN LIMITED | Contacts Not Included | Gray | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 12 | |
 BULGIN LIMITED | Contacts Not Included | Gray | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 8 | |
 BULGIN LIMITED | Contacts Not Included | Black | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | ||
 BULGIN LIMITED | Contacts Not Included | Black | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 4 | |
 BULGIN LIMITED | Contacts Not Included | Black | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 2 | 1 | |
 BULGIN LIMITED | Contacts Not Included | Gray | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 3 | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 6 | |
 BULGIN LIMITED | Contacts Not Included | Gray | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 120 °C | -40 C | Glass Filled Nylon Polyamide (PA) Polybutylene Terephthalate (PBT) | Cap (Cover) IP68 | 2 | 1 | |
 BULGIN LIMITED | Contacts Not Included | Black | Latch Lock | Plug | Free Hanging (In-Line) | Crimp | Female Socket Power | 2 | 120 °C | -40 C | Polybutylene Terephthalate (PBT) Glass Filled | Cap (Cover) IP68 | 12 |
