TG-A4500 Series
Manufacturer: t-Global Technology
Beta
⌘K
THERM PAD 320X320MM PURP
| Part | Shelf Life | Type | Outline [x] | Outline [y] | Adhesive | Usage | Backing, Carrier [custom] | Backing, Carrier [custom] | Color | Shape | Material | Thermal Conductivity | Thickness | Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 t-Global Technology | 24 Months | Gap Filler Pad Sheet | 320 mm | 320 mm | Tacky - One Side | Multi | Fiberglass | Fiberglass | Purple | Square | Silicone | 4 W/m-K | 0.0394 " | 1 mm |
 t-Global Technology | 24 Months | Gap Filler Pad Sheet | 10 mm | 10 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.197 in | 5 mm | ||
 t-Global Technology | 24 Months | Gap Filler Pad Sheet | 10 mm | 10 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.079 in | 2 mm | ||
t-Global Technology | 24 Months | Gap Filler Pad Sheet | 320 mm | 320 mm | Tacky - One Side | Multi | Fiberglass | Fiberglass | Purple | Square | Silicone | 4 W/m-K | 0.0197 " | 0.5 mm |
 t-Global Technology | 24 Months | Gap Filler Pad Sheet | 30 mm | 30 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.157 in | 4 mm | ||
t-Global Technology | 24 Months | Gap Filler Pad Sheet | 40 mm | 40 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.157 in | 4 mm | ||
t-Global Technology | 24 Months | Gap Filler Pad Sheet | 40 mm | 40 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.118 in | 3 mm | ||
t-Global Technology | 24 Months | Gap Filler Pad Sheet | 25 mm | 25 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.0394 " | 1 mm | ||
 t-Global Technology | 24 Months | Gap Filler Pad Sheet | 30 mm | 30 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.118 in | 3 mm | ||
t-Global Technology | 24 Months | Gap Filler Pad Sheet | 25 mm | 25 mm | Tacky - Both Sides | Multi | Purple | Square | Silicone | 4.5 W/m-K | 0.197 in | 5 mm |
