895-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 23POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Color | Card Thickness [Max] | Card Thickness [Min] | Termination | Card Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Read Out | Number of Rows | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Contact Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 3.25 mm | 0.128 " | Cantilever | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | Cantilever | Gold | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 3.96 mm | 0.156 " | Cantilever | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 2.95 mm | 0.116 " | Cantilever | Gold | Floating Bobbin Flush Mount |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 2.95 mm | 0.116 " | Cantilever | Gold | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 3.25 mm | 0.128 " | Cantilever | Gold | Side Mount Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Right Angle Through Hole | 23 | 3.25 mm | 0.128 " | Cantilever | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 2.95 mm | 0.116 " | Cantilever | Gold | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | Cantilever | Gold | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 125 °C | -40 C | 23 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Single | 1 | 0.1 " | 2.54 mm | Through Hole | 23 | 3.25 mm | 0.128 " | Cantilever | Gold |
