3057P Series

Catalog

TRIMMER 20 OHM 1W PC PIN SIDE

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Resistance	Resistive Material	Number of Turns	Tolerance	Adjustment Type	Termination Style	Power (Watts)	Temperature Coefficient
Bourns Inc. 3057P-1-200	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	20 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-501M	0.315 in	4.83 mm	0.19 in	8 mm	Panel Mount Through Hole	0.5 kOhms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-202	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	2 kOhms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-102M	0.315 in	4.83 mm	0.19 in	8 mm	Panel Mount Through Hole	1000 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-101	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	100 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-202M	0.315 in	4.83 mm	0.19 in	8 mm	Panel Mount Through Hole	2 kOhms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-253	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	25 kOhms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-503	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	50000 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-100	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	10 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
Bourns Inc. 3057P-1-103	0.315 in	4.83 mm	0.19 in	8 mm	Chassis Mount	10000 Ohms	Wirewound	22	5 %	Side Adjustment	PC Pins	1 W	50 ppm/░C
