68779 Series

Catalog

BERGSTIK II DR STR

Part	Contact Length - Post	Contact Length - Post	Contact Material	Connector Type	Mounting Type	Contact Shape	Contact Length - Mating [x]	Contact Length - Mating [x]	Fastening Type	Number of Positions Loaded	Insulation Color	Material Flammability Rating	Overall Contact Length	Overall Contact Length	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Number of Rows	Termination	Number of Positions	Insulation Height	Insulation Height	Contact Type	Shrouding	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish - Mating	Contact Finish - Post
Amphenol ICC (FCI) 68779-150H	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	2	Solder	50	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68779-452HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	52	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
Amphenol ICC (FCI) 68779-102HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	30 Áin	0.76 Ám			2	Solder	2	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68779-436HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	36	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
Amphenol ICC (FCI) 68779-450HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	50	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
Amphenol ICC (FCI) 68779-272HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	15 µin	0.38 µm	0.1 in	2.54 mm	2	Solder	72	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68779-420HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	20	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
Amphenol ICC (FCI) 68779-458HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	58	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
Amphenol ICC (FCI) 68779-172HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	2	Solder	72	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68779-418HLF	0.318 in	8.08 mm	Phosphor Bronze	Header	Through Hole	Square	0.318 "	8.08 mm	Push-Pull	All	Black	UL94 V-0	0.736 in	18.69 mm	100 çin	2.54 çm	0.1 in	2.54 mm	2	Solder	18	0.1 in	2.54 mm	Male Pin	Unshrouded	-65 ░C	130 °C	3 A	2.54 mm	0.1 in		Tin
