SM31TB Series

Manufacturer: Nidec Components Corporation

Catalog

TRIMMER 2K OHM 0.125W GW SIDE

Part	Termination Style	Mounting Type	Adjustment Type	Temperature Coefficient	Size / Dimension [x]	Size / Dimension [y]	Resistance	Tolerance	Resistive Material	Power (Watts)	Power (Watts)	Number of Turns
Nidec Components Corporation SM-31TB202	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	2 kOhms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB502	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	5 kOhms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB503	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	50 kOhms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB203	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	20 kOhms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB201	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	200 Ohms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB103	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	10000 Ohms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB105	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	1 MOhms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB101	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	100 Ohms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB204	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	200000 Ohms	20 %	Cermet	0.125 W	0.125 W	5
Nidec Components Corporation SM-31TB501	Gull Wing	Surface Mount	Side Adjustment	100 ppm/°C	0.173 in 4.4 mm	0.154 in 3.9 mm	500 Ohms	20 %	Cermet	0.125 W	0.125 W	5
