Fixed Terminal Blocks FRONT 2 5-H/SA 5 BK
Fixed Terminal Blocks FRONT 2 5-H/SA 5 BK
| Part | Positions Per Level | Voltage | Color | Current | Mounting Type | Wire Gauge [Max] | Wire Gauge [Min] | Number of Levels | Wire Termination | Mating Orientation | Features | Screw Thread | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Housing Material | Contact Material - Plating | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 1 | 300 VDC | Black | 20 A | Through Hole | 30 AWG | 12 AWG | 1 | Screw - Rising Cage Clamp | Horizontal with Board | Interlocking (Side) | |||||||||
 Phoenix Contact | 4 | Green | Through Hole | 24 AWG | 14 AWG | 1 | Screw - Pressure Clip | Horizontal with Board | M2.5 | 4.4 Lb-In | 3.5 Lb-In | 0.4 Nm | 0.5 Nm | Polyamide (PA) Nylon | Tin Plated | 0.197 in | 5 mm |
