HSCSFNT Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SENSOR 5.8PSIG 0.19" 4.5V 4SIP
| Part | Pressure Type | Mounting Type | Maximum Pressure [Max] | Maximum Pressure [Max] | Voltage - Supply [Min] | Voltage - Supply [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Accuracy | Package / Case | Port Style | Features | Termination Style | Output Type | Output [Min] | Output [Max] | Port Size | Operating Pressure | Operating Pressure | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Vented Gauge | Through Hole | 200 kPa | 29.01 PSI | 4.75 V | 5.25 V | 85 °C | -20 C | Board Mount | 0.25 % | 4-SIP Side Port | Barbed | Amplified Output Temperature Compensated | PC Pin | Analog Voltage | 0.5 V | 4.5 V | 4.78 mm 4.826 mm | 40 kPa | 5.8 PSI | 4-SIP |
