PN10 Series

Catalog

CONN RING CIRC 10-12AWG #6 CRIMP

Part	Material - Insulation	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Wire Gauge [Min]	Wire Gauge [Max]	Stud/Tab Size	Mounting Type	Length - Overall [x]	Length - Overall [x]	Contact Material	Terminal Type	Contact Finish	Color	Thickness	Thickness	Features	Termination	Width - Outer Edges [x]	Width - Outer Edges [x]	Insulation	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Insulation Diameter [diameter]	Width - Outer Edges [y]	Width - Outer Edges [y]	Width - Outer Edges	Width - Outer Edges	Length - Overall	Length - Overall	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]	Tongue Inside Opening	Tongue Inside Opening	Tongue Inside Opening [diameter]	Tongue Inside Opening [diameter]
Panduit Corp PN10-6R-2K	Nylon Polyamide (PA)	5.84 mm	0.23 in	10 AWG	12 AWG	6 Stud	Free Hanging (In-Line)	27 mm	1.063 in	Copper	Circular	Tin	Yellow	0.04 in	1.02 mm	Serrated Termination	Crimp	9.7 mm	0.382 in	Insulated
Panduit Corp PN10-10FF-D	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	10 Stud	Free Hanging (In-Line)	26.67 mm	1.05 in	Copper	Flanged	Tin	Yellow			Brazed Seam Serrated Termination	Crimp			Insulated	0.2 in	5.08 mm	5.72 mm	0.37 in	9.4 mm
Panduit Corp PN10-56R-D	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	0.3125 Stud	Free Hanging (In-Line)	30.73 mm	1.21 "	Copper	Circular	Tin	Yellow	0.04 in	1.02 mm		Crimp			Insulated			5.72 mm			0.52 in	13.21 mm
Panduit Corp PN10-10R-L	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	10 Stud	Free Hanging (In-Line)			Copper	Circular	Tin	Yellow	0.04 in	1.02 mm		Crimp	9.65 mm	0.38 in	Insulated			5.72 mm					1.06 in	26.92 mm
Panduit Corp PN10-8RN-D	Nylon Polyamide (PA)			10 AWG	12 AWG	8 Stud	Free Hanging (In-Line)	26.42 mm	1.04 in	Copper	Circular	Tin	Yellow	0.04 in	1.02 mm		Crimp			Insulated				0.311 in	7.9 mm					3.05 mm	0.225 in	0.12 "	5.72 mm
Panduit Corp PN10-38R-2K	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	0.375 Stud	Free Hanging (In-Line)				Circular	Tin	Yellow	0.04 in	1.02 mm	Serrated Termination	Crimp	14.73 mm	0.58 in	Insulated			5.72 mm					1.29 in	32.77 mm
Panduit Corp PN10-14F-D	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	0.25 Stud	Free Hanging (In-Line)	28.96 mm	1.14 in	Copper	Standard	Tin	Yellow				Crimp			Insulated			5.72 mm	0.49 in	12.45 mm									0.27 in	6.86 mm
Panduit Corp PN10-6F-D	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	6 Stud	Free Hanging (In-Line)			Copper	Standard	Tin	Yellow			Butted Seam	Crimp			Insulated			5.72 mm			0.31 in	7.87 mm	1 in	25.4 mm					0.15 in	3.81 mm
Panduit Corp PN10-12R-E	Nylon Polyamide (PA)			10 AWG	12 AWG	0.5 Stud	Free Hanging (In-Line)	37.34 mm	1.47 in	Copper	Circular	Tin	Yellow	0.04 in	1.02 mm	Serrated Termination	Crimp			Insulated						0.72 in	18.29 mm			3.05 mm	0.225 in	0.12 "	5.72 mm
Panduit Corp PN10-8FF-L	Nylon Polyamide (PA)	0.225 "		10 AWG	12 AWG	8 Stud	Free Hanging (In-Line)	26.67 mm	1.05 in	Copper	Flanged	Tin	Yellow			Brazed Seam Serrated Termination	Crimp			Insulated			5.72 mm	0.37 in	9.4 mm											0.17 in	4.32 mm
