MAX17690 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

EVAL BOARD FOR MAX17690

Part	Power - Output	Voltage - Input [Max]	Voltage - Input [Min]	Board Type	Supplied Contents	Regulator Topology	Utilized IC / Part	Main Purpose	Current - Output	Outputs and Type	Outputs and Type	Voltage - Output	Supplier Device Package	Mounting Type	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Control Features	Number of Outputs	Output Phases	Package / Case	Frequency - Switching [Min]	Frequency - Switching [Max]	Duty Cycle (Max)	Output Configuration	Output Type	Topology	Function	Contents	Frequency - Switching
Analog Devices Inc./Maxim Integrated MAX17690EVKITA#	5 W	36 V	18 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Converter	1 A	Isolated	1	5 V
Analog Devices Inc./Maxim Integrated MAX17690ATE/V+T													16-TQFN (3x3)	Surface Mount	4.5 V	60 V	-40 °C	125 °C	Current Limit Enable Frequency Control Soft Start	1	1	16-WFQFN Exposed Pad	50 kHz	250 kHz	69 %	Isolation Capable Positive	Transistor Driver	Flyback	Step-Up/Step-Down
Analog Devices Inc./Maxim Integrated MAX17690EVKITG#	5 W	5.5 V	4.5 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Step Up or Down	1 A	1 Isolated Output Isolated	1	5 V																		Board(s)	180 kHz
Analog Devices Inc./Maxim Integrated MAX17690EVKITE#	16.5 W	36 V	18 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Step Down	5 A	Isolated	1	3.3 V																			200 kHz
Analog Devices Inc./Maxim Integrated MAX17690EVKITC#		36 V	18 V	Fully Populated	Board(s)	Flyback	750343182 MAX17690	DC/DC Step Down	200 mA	Isolated	2	15 V																			100 kHz
Analog Devices Inc./Maxim Integrated MAX17690EVKITD#	15 W	36 V	18 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Step Down	3 A	Isolated	1	5 V																			200 kHz
Analog Devices Inc./Maxim Integrated MAX17690ATE+													16-TQFN (3x3)	Surface Mount	4.5 V	60 V	-40 °C	125 °C	Current Limit Enable Frequency Control Soft Start	1	1	16-WFQFN Exposed Pad	50 kHz	250 kHz	69 %	Isolation Capable Positive	Transistor Driver	Flyback	Step-Up/Step-Down
Analog Devices Inc./Maxim Integrated MAX17690EVKITB#		36 V	18 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Step Down	1 A	Isolated	1	5 V																			180 kHz
Analog Devices Inc./Maxim Integrated MAX17690EVKITJ#	25 W	80 V	40 V	Fully Populated	Board(s)	Flyback	MAX17690	DC/DC Step Down	2.1 A	Isolated	1	12 V																			100 kHz
Analog Devices Inc./Maxim Integrated MAX17690ATE+T													16-TQFN (3x3)	Surface Mount	4.5 V	60 V	-40 °C	125 °C	Current Limit Enable Frequency Control Soft Start	1	1	16-WFQFN Exposed Pad	50 kHz	250 kHz	69 %	Isolation Capable Positive	Transistor Driver	Flyback	Step-Up/Step-Down
