MI-J23 Series

Catalog

DC DC CONVERTER 24V 50W

Part	Voltage - Isolation	Mounting Type	Voltage - Input (Max) [Max]	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Type	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Voltage - Output 1	Voltage - Input (Min) [Min]	Power (Watts)	Efficiency	Package / Case	Current - Output (Max) [Max]	Number of Outputs	Features
Vicor Corporation MI-J23-MY-F2	3000 V	Through Hole	50 V	ITE (Commercial)	-55 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	50 W	90 %	9-DIP Module	2.083 A	1	OCP OTP OVP Remote On/Off
Vicor Corporation MI-J23-IY-F3	3000 V	Through Hole	50 V	ITE (Commercial)	-40 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	50 W	90 %	9-DIP Module	2.083 A	1	OCP OTP OVP Remote On/Off
Vicor Corporation MI-J23-IY	3000 V	Through Hole	50 V	ITE (Commercial)	-40 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	50 W	90 %	9-DIP Module	2.083 A	1	OCP OTP OVP Remote On/Off
Vicor Corporation MI-J23-IY-F2	3000 V	Through Hole	50 V	ITE (Commercial)	-40 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	50 W	90 %	9-DIP Module	2.083 A	1	OCP OTP OVP Remote On/Off
Vicor Corporation MI-J23-MZ	3000 V	Through Hole	50 V	ITE (Commercial)	-55 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	25 W	90 %	9-DIP Module	1.04 A	1	OCP OTP OVP Remote On/Off
Vicor Corporation MI-J23-IZ	3000 V	Through Hole	50 V	ITE (Commercial)	-40 C	85 °C	Isolated Module	57.9 mm	2.28 in	2.4 in	0.5 in	61 mm	12.7 mm	24 V	18 V	25 W	90 %	9-DIP Module	1.04 A	1	OCP OTP OVP Remote On/Off
