857-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 20POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Read Out | Number of Rows | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Card Type | Mounting Type | Number of Positions | Color | Contact Type | Pitch | Pitch | Contact Material | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Single | 1 | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Non Specified - Single Edge | Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Single | 1 | Female | Solder Eyelet(s) | Non Specified - Single Edge | Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | |||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Dual | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap | Non Specified - Dual Edge | Through Hole | 40 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Dual | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Non Specified - Dual Edge | Right Angle Through Hole | 40 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Dual | Female | Flush Mount M3 Threaded Insert Top Opening | Solder | Non Specified - Dual Edge | Right Angle Through Hole | 40 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Dual | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Non Specified - Dual Edge | Right Angle Through Hole | 40 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Single | 1 | Female | Solder | Non Specified - Single Edge | Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 10 | Dual | Female | Solder | Non Specified - Dual Edge | Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 2 | |||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 20 Bay/Row | Single | 1 | Female | Flush Mount M3 Threaded Insert Top Opening | Solder | Non Specified - Single Edge | Right Angle Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 10 | Single | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Non Specified - Dual Edge | Right Angle Through Hole | 20 | Black | Semi Bellows | 3.96 mm | 0.156 in | Copper Alloy | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 2 |
