25093 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 3COND 24AWG ORG 1000=1000'
| Part | Shield Material | Shield Coverage | Conductor Insulation | Shield Type | Jacket Color | Features | Operating Temperature [Min] | Operating Temperature [Max] | Ratings | Wire Gauge | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Conductor Strand [custom] | Conductor Strand [custom] | Number of Conductors | Voltage | Conductor Material | Spool Size [x] | Spool Size [x] | Length | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) | Foil | Orange | Biological Compatibility Drain Wire Rip Cord | -30 ░C | 90 °C | ISO 10993 UL Style 20668 | 24 AWG | Polyurethane (PU) | 4.24 mm | 0.167 in | 0.813 mm | 0.032 in | Multi-Conductor | 7 | 32 AWG | 3 | 300 VDC | Copper Tinned | |||||
 ALPHA WIRE | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) | Foil | Black | Biological Compatibility Drain Wire Rip Cord | -30 ░C | 90 °C | ISO 10993 UL Style 20668 | 24 AWG | Polyurethane (PU) | 4.24 mm | 0.167 in | 0.813 mm | 0.032 in | Multi-Conductor | 7 | 32 AWG | 3 | 300 VDC | Copper Tinned | 304.8 m | 1000 ft | Enter Number of Feet in Order Quantity | ||
ALPHA WIRE | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) | Foil | Slate | Biological Compatibility Drain Wire Rip Cord | -30 ░C | 90 °C | ISO 10993 UL Style 20668 | 24 AWG | Polyurethane (PU) | 4.24 mm | 0.167 in | 0.813 mm | 0.032 in | Multi-Conductor | 7 | 32 AWG | 3 | 300 VDC | Copper Tinned | 304.8 m | 1000 ft |
