MKS1T Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE SPST 15A 12V
| Part | Contact Rating (Current) | Contact Form | Features | Mounting Type | Switching Voltage | Must Release Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Release Time | Approval Agency | Operate Time | Coil Current | Coil Resistance | Relay Type | Coil Type | Coil Voltage | Must Operate Voltage | Load - Max Switching | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | 15 A | SPST-NO (1 Form A) | Lighted Indicator | Socketable | 250 VAC | 1.8 VDC | -25 °C | 60 °C | Plug In | 20 ms | cURus TUV | 30 ms | 126 mA | 95 Ohms | General Purpose | Non Latching | 12 VDC | 9.6 VDC | 3750 VA | Silver Tin Indium (AgSnIn) |
 Omron Electronics Inc-EMC Div | 15 A | SPST-NO (1 Form A) | Lighted Indicator | Socketable | 250 VAC | 36 VAC | -25 °C | 60 °C | Plug In | 20 ms | cURus TUV | 20 ms | 19.3 mA | 1130 Ohms | General Purpose | Non Latching | 120 VAC | 96 VAC | 3750 VA | Silver Tin Indium (AgSnIn) |
 Omron Electronics Inc-EMC Div | 15 A | SPST-NO (1 Form A) | Lighted Indicator Test Button | Socketable | 250 VAC | 69 VAC | -25 °C | 60 °C | Plug In | 20 ms | cURus TUV | 20 ms | 10 mA | 4.25 kOhms | General Purpose | Non Latching | 230 VAC | 184 VAC | 3750 VA | Silver Tin Indium (AgSnIn) |
 Omron Electronics Inc-EMC Div | 15 A | SPST-NO (1 Form A) | Lighted Indicator Test Button | Socketable | 250 VAC | 7.2 VAC | -25 °C | 60 °C | Plug In | 20 ms | cURus TUV | 20 ms | 96.3 mA | 48.4 Ohms | General Purpose | Non Latching | 24 VAC | 19.2 VAC | 3750 VA | Silver Tin Indium (AgSnIn) |
 Omron Electronics Inc-EMC Div | 15 A | SPST-NO (1 Form A) | Lighted Indicator Test Button | Socketable | 250 VAC | 33 VAC | -25 °C | 60 °C | Plug In | 20 ms | cURus TUV | 20 ms | 21 mA | 932 Ohms | General Purpose | Non Latching | 110 VAC/DC | 88 VAC/DC | 3750 VA | Silver Tin Indium (AgSnIn) |
