845-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 35POS 0.100
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Read Out | Gender | Contact Type | Number of Rows | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Color | Pitch | Pitch | Card Type | Flange Feature | Contact Material | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | M3 Threaded Insert Top Mount Opening | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | Copper Alloy | Solder Eyelet(s) | 125 °C | -40 C | 35 | Gold | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Wire Wrap | 125 °C | -40 C | 35 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Floating Bobbin Flush Mount | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | 35 | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 35 | Single | Female | Cantilever | 1 | Through Hole | 0.25 Ám | 10 Áin | Green | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | Solder Eyelet(s) | 125 °C | -40 C | 35 | Gold | 0.156 " | 3.96 mm |
