CBTL06 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
IC MULTIPLEXER TRPL 1X2 56HVQFN
| Part | Mounting Type | Operating Temperature (Max) | Operating Temperature (Min) | Package Name | Package Length | Package Width | Applications | Multiplexer Inputs | Demultiplexer Outputs | Features | Number of Channels | Package / Case | -3db Bandwidth | Voltage - Supply, Single (V+) (Minimum) | Voltage - Supply, Single (V+) (Maximum) | Multiplexer/Demultiplexer Circuit | On-State Resistance (Typ) | On-State Resistance (Max) | Voltage - Supply, Single (V+) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Surface Mount | 85 °C | -40 °C | 56-HWQFN | 5 mm | 11 mm | DisplayPort PCIe | 2 | 1 | Bi-Directional | 6 | 56-WFQFN Exposed Pad | 2.5 GHz | 3 V | 3.6 V | ||||
 NXP USA Inc. | Surface Mount | 85 °C | -40 °C | 48-TFBGA | 5 mm | 5 mm | DisplayPort PCIe Video | DVI HDMI | 6 | 48-TFBGA | 2 GHz | 3 V | 3.6 V | 2:1 4:1 | |||||
NXP USA Inc. | Surface Mount | 105 °C | -40 °C | 48-TFBGA | 5 mm | 5 mm | DisplayPort PCIe | Bi-Directional | 6 | 48-TFBGA | 11.1 GHz | 3 V | 3.6 V | 2:1 4:1 | 14 Ohm | ||||
NXP USA Inc. | Surface Mount | 85 °C | -40 °C | 48-TFBGA | 5 mm | 5 mm | DisplayPort PCIe | Bi-Directional | 6 | 48-TFBGA | 5 GHz | 3 V | 3.6 V | 2:1 4:1 | 6.5 Ohm | ||||
NXP USA Inc. | Surface Mount | 85 °C | -40 °C | 56-HWQFN | 5 mm | 11 mm | DisplayPort PCIe | 2 | 1 | Bi-Directional | 6 | 56-WFQFN Exposed Pad | 2.5 GHz | 3 V | 3.6 V | ||||
 NXP USA Inc. | Surface Mount | 105 °C | -40 °C | 50-TFBGA | 5 mm | 5 mm | DisplayPort PCIe Video | 2 | 1 | Bi-Directional HDMI | 6 | 50-TFBGA | 9.5 GHz | 3 V | 3.6 V | 10 Ohm | |||
NXP USA Inc. | Surface Mount | 85 °C | -40 °C | 56-HWQFN | 5 mm | 11 mm | DisplayPort PCIe | 2 | 1 | Bi-Directional | 6 | 56-WFQFN Exposed Pad | 2.5 GHz | 3 V | 3.6 V | ||||
NXP USA Inc. | Surface Mount | 105 °C | -40 °C | 48-TFBGA | 5 mm | 5 mm | DisplayPort PCIe | Bi-Directional | 6 | 48-TFBGA | 5 GHz | 2:1 4:1 | 6 Ohms | 3.3 V |
