1565036 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
EP CONN. HDR ASSY 5/6P W/O#5 BLUE
| Part | Fastening Type | Insulation Material | Style | Applications | Pitch - Mating | Pitch - Mating | Connector Type | Insulation Height | Insulation Height | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Type | Material Flammability Rating | Termination | Number of Positions | Number of Positions Loaded [custom] | Shrouding | Contact Length - Post | Contact Length - Post | Number of Rows | Contact Material | Insulation Color | Contact Length - Mating | Contact Length - Mating | Contact Shape | Contact Finish - Post | Overall Contact Length | Overall Contact Length | Current Rating (Amps) | Number of Positions Loaded | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Locking Ramp | Polybutylene Terephthalate (PBT) Glass Filled | Board to Cable/Wire | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | Header | 0.362 in | 9.2 mm | Through Hole | -25 °C | 105 ░C | 250 VAC | Male Pin | UL94 V-0 | Solder | 6 | 5 | Shrouded - 1 Wall | 0.146 in | 3.7 mm | 1 | Brass | Blue | 7.7 mm | 0.303 in | Square | Tin | 14.4 mm | 0.567 " | 7.5 A | ||
TE Connectivity Raychem Cable Protection | Locking Ramp | Polybutylene Terephthalate (PBT) Glass Filled | Board to Cable/Wire | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | Header | 0.362 in | 9.2 mm | Through Hole | -25 °C | 105 ░C | 250 VAC | Male Pin | UL94 V-0 | Solder | 7 | 5 | Shrouded - 1 Wall | 0.146 in | 3.7 mm | 1 | Brass | Natural | 7.7 mm | 0.303 in | Square | Tin | 14.4 mm | 0.567 " | 7.5 A | ||
 TE Connectivity Raychem Cable Protection | Locking Ramp | Glass Filled Nylon Polyamide (PA) | Board to Cable/Wire | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | Header | 0.362 in | 9.2 mm | Through Hole | -25 °C | 105 ░C | 250 VAC | Male Pin | UL94 V-2 | Solder | Shrouded - 1 Wall | 0.146 in | 3.7 mm | 1 | Brass | Natural | 7.7 mm | 0.303 in | Square | Tin | 14.4 mm | 0.567 " | 7.5 A | 4 | Glow Wire Compliant |
