3016-0 Series

Catalog

CONN PIN RCPT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness	Contact Finish Thickness	Contact Finish	Tail Type	Termination	Flange Diameter [diameter]	Flange Diameter [diameter]	Socket Depth	Socket Depth	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Mounting Hole Diameter	Mounting Hole Diameter	Length - Overall [x]	Length - Overall [x]	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Contact Material
Mill-Max Manufacturing Corp. 3016-0-15-80-21-14-10-0	-55 C	125 °C	0.25 Ám	10 Áin	Gold	No Tail	Solder	0.048 in	1.22 mm	3.51 mm	0.138 in	0.38 mm	0.022 in	0.015 "	0.56 mm	0.91 mm	0.036 in	3.94 mm	0.155 in	0.031 in	0.79 mm	Beryllium Copper
Mill-Max Manufacturing Corp. 3016-0-15-15-21-14-10-0	-55 C	125 °C	0.25 Ám	10 Áin	Gold	No Tail	Solder	0.048 in	1.22 mm	3.51 mm	0.138 in	0.38 mm	0.022 in	0.015 "	0.56 mm	0.91 mm	0.036 in	3.94 mm	0.155 in	0.031 in	0.79 mm	Beryllium Copper
Mill-Max Manufacturing Corp. 3016-0-15-01-21-14-10-0	-55 C	125 °C	0.25 Ám	10 Áin	Gold	No Tail	Solder	0.048 in	1.22 mm	3.51 mm	0.138 in	0.38 mm	0.022 in	0.015 "	0.56 mm	0.91 mm	0.036 in	3.94 mm	0.155 in	0.031 in	0.79 mm	Beryllium Copper
Mill-Max Manufacturing Corp. 3016-0-15-15-21-27-10-0	-55 C	125 °C	0.76 Ám	30 Áin	Gold	No Tail	Solder	0.048 in	1.22 mm	3.51 mm	0.138 in	0.38 mm	0.022 in	0.015 "	0.56 mm	0.91 mm	0.036 in	3.94 mm	0.155 in	0.031 in	0.79 mm	Beryllium Copper
