RT9073 Series
Manufacturer: Richtek USA Inc.
Beta
⌘K
IC REG LINEAR 1.8V 250MA 4ZQFN
| Part | Protection Features | PSRR | Mounting Type | Current - Quiescent (Iq) | Output Configuration | Control Features | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Voltage - Output (Min/Fixed) | Current - Output | Number of Regulators | Supplier Device Package | Voltage - Input (Max) [Max] | Voltage Dropout (Max) | Voltage - Output (Min/Fixed) [Min] | Current - Supply (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 4-XDFN Exposed Pad | 1.8 V | 250 mA | 1 | 4-ZQFN (1x1) | 5.5 V | 0.8 V | ||
 Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | SC-74A SOT-753 | 2.3 V | 250 mA | 1 | SOT-23-5 | 5.5 V | 0.8 V | ||
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 4-XDFN Exposed Pad | 2.8 V | 250 mA | 1 | 4-ZQFN (1x1) | 5.5 V | 0.6 V | ||
Richtek USA Inc. | Over Current Over Temperature | Surface Mount | 3 µA | Positive | Current Limit Enable | 85 C | -40 ¯C | 4-XDFN Exposed Pad | 250 mA | 1 | 4-ZQFN (1x1) | 5.5 V | 0.8 V | 1.9 V | |||
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | SC-74A SOT-753 | 0.9 V | 250 mA | 1 | SOT-23-5 | 5.5 V | 1.45 V | ||
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | SC-74A SOT-753 | 1.8 V | 250 mA | 1 | SOT-23-5 | 5.5 V | 0.8 V | ||
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 4-XDFN Exposed Pad | 1.2 V | 250 mA | 1 | 4-ZQFN (1x1) | 5.5 V | 1.2 V | 500 µA | |
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 5-TSSOP SC-70-5 SOT-353 | 1.2 V | 250 mA | 1 | SC-70-5 | 5.5 V | 1.2 V | ||
Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 4-XDFN Exposed Pad | 0.9 V | 250 mA | 1 | 4-ZQFN (1x1) | 5.5 V | 1.45 V | ||
 Richtek USA Inc. | Over Current Over Temperature | 75 dB | Surface Mount | 3 µA | Positive | Enable | 85 C | -40 ¯C | 5-TSSOP SC-70-5 SOT-353 | 3 V | 250 mA | 1 | SC-70-5 | 5.5 V | 0.6 V |
