MT-4B Series

Catalog

3-IN-1 COMBO EXTERNAL ANTENNA

Part	Number of Bands	Gain	VSWR	Frequency Group	Return Loss	Features	Applications	Height (Max) [z]	Height (Max) [z]	Frequency (Center/Band)	Antenna Type	Mounting Type	RF Family/Standard	Frequency Range [Max]	Frequency Range [Min]	Height (Max) [Max] [z]	Height (Max)
Unictron Technologies Corporation MT-4B-AS-BL03	12	-1 dBi 1.21 dBi 1.44 dBi 3.19 dBi 3.62 dBi 4.24 dBi 4.31 dBi 4.46 dBi 4.77 dBi 4.89 dBi 6.44 dBi 6.97 dBi 7.12 dBi 7.23 dBi 7.87 dBi	2 3	Wide Band	-10 dB -6 dB	Cable - 3m	BeiDou DCS Galileo GLONASS GNSS GPS GSM LTE PCS UMTS Wi-Fi	15.8 mm	0.622 in	1.561 GHz 1.575 GHz 1.602 GHz 1.795 GHz 1.92 GHz 2.045 GHz 2.4 GHz 2.495 GHz 3.55 GHz 5.8 GHz 761 MHz 892 MHz	Module	Adhesive Magnetic	Cellular Navigation WiFi	1.563 GHz 1.576 GHz 1.607 GHz 1.88 GHz 1.99 GHz 2.17 GHz 2.69 GHz 3.8 GHz 824 MHz 960 MHz	1.559 GHz 1.574 GHz 1.597 GHz 1.71 GHz 1.85 GHz 1.92 GHz 2.3 GHz 3.3 GHz 698 MHz 824 MHz
Unictron Technologies Corporation MT-4B-AC-BL03	9	-2.17 dBi 0.15 dBi 1.21 dBi 1.44 dBi 2.52 dBi 2.71 dBi 7.93 dBi	2	Wide Band	-10 dB	Cable - 5m	BeiDou DCS Galileo GLONASS GNSS GPS GSM LTE PCS UMTS			1.561 GHz 1.575 GHz 1.602 GHz 1.795 GHz 1.92 GHz 2.045 GHz 2.495 GHz 761 MHz 892 MHz	Module	Screw Mount	Cellular Navigation	1.563 GHz 1.576 GHz 1.607 GHz 1.88 GHz 1.99 GHz 2.17 GHz 2.69 GHz 824 MHz 960 MHz	1.559 GHz 1.574 GHz 1.597 GHz 1.71 GHz 1.85 GHz 1.92 GHz 2.3 GHz 698 MHz 824 MHz	0.787 in	20 mm
