092316 Series

Manufacturer: Molex

Catalog

18CKT PICOFLEX HARNESS 70MM LONG

Part	Number of Positions	Shielding	Contact Finish Thickness	Contact Finish Thickness	Number of Rows	Cable Termination	Length	Length	Length	Contact Finish	Pitch - Cable	Pitch - Cable	Connector Type	Pitch - Connector	Pitch - Connector	Number of Positions	Length [x]	Length [x]	Length [x]
Molex 0923161807	18	Unshielded	80 Áin	2.03 Ám	2	IDC	0.23 ft	2.76 in	70 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923162422	24	Unshielded	80 Áin	2.03 Ám	2	IDC	0.722 ft	8.66 in	220 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923161010	10	Unshielded	80 Áin	2.03 Ám	2	IDC	0.328 '	3.94 "	100 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923161610		Unshielded	80 Áin	2.03 Ám	2	IDC	0.328 '	3.94 "	100 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm	16
Molex 0923162010	20	Unshielded	80 Áin	2.03 Ám	2	IDC	0.328 '	3.94 "	100 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923162606	26	Unshielded	80 Áin	2.03 Ám	2	IDC	0.197 ft	2.36 in	59.94 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923161015	10	Unshielded	80 Áin	2.03 Ám	2	IDC	0.492 ft	5.91 "	150 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
Molex 0923160608	6	Unshielded	80 Áin	2.03 Ám	2	IDC				Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm		80.01 mm	0.263 '	3.15 in
Molex 0923160808	8	Unshielded	80 Áin	2.03 Ám	2	IDC				Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm		80.01 mm	0.263 '	3.15 in
Molex 0923162618	26	Unshielded	80 Áin	2.03 Ám	2	IDC	0.59 ft	7.08 "	180 mm	Tin	0.05 "	1.27 mm	Socket to Socket	0.1 in	2.54 mm
