627-3W3 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 3P PNL MNT SLDR
| Part | Dielectric Material | Voltage Rating | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Connector Style | Current Rating (Amps) | Contact Finish Thickness | Mounting Type | Material Flammability Rating | Contact Finish | Flange Feature [custom] | Flange Feature [custom] | Contact Type | Connector Type | Shell Size, Connector Layout | Termination | Shell Material, Finish | Features | Number of Rows | Flange Feature | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 20 A | Flash | Panel Mount | UL94 V-0 | Gold | 4-40 | 4-40 | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Grounding Indents Shielded | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 10 A | Flash | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Grounding Indents Shielded | 1 | Board Side (M3) | |||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 30 A | Flash | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Grounding Indents Shielded | 1 | Board Side (4-40) | |||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 20 A | Flash | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Grounding Indents Shielded | 1 | Board Side (4-40) | ||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 10 A | Free Hanging (In-Line) | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Nickel Plated Steel | Grounding Indents Shielded | 1 | Board Side (M3) | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | Through Hole | UL94 V-0 | Gold | Coax | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Board Lock Grounding Indents Shielded | 1 | Board Side (4-40) | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 10 A | Flash | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Grounding Indents Shielded | 1 | Board Side (M3) | ||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 30 A | Flash | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Grounding Indents Shielded | 1 | Board Side (M3) | ||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | 30 A | Panel Mount | UL94 V-0 | Gold | Power | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Grounding Indents Shielded | 1 | Board Side (4-40) | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | Copper Alloy | Black | -55 C | 125 °C | 3 | Combo D-Sub | Through Hole | UL94 V-0 | Gold | Coax | Plug Male Pins | 2 (DA A) - 3W3 | Solder | Nickel Plated Steel | Board Lock Grounding Indents Shielded | 1 | Board Side (M3) | 30 Áin | 0.76 Ám |
