895-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 15POS 0.100
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Card Type | Termination | Contact Finish | Mounting Type | Number of Positions/Bay/Row | Number of Positions | Contact Material | Read Out | Number of Rows | Flange Feature | Contact Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Color | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Wire Wrap | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | M3 Threaded Insert Top Mount Opening | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Right Angle Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Floating Bobbin Top Mount Opening | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | M3 Threaded Insert Top Mount Opening | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Wire Wrap | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | M3 Threaded Insert Top Mount Opening | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Right Angle Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Floating Bobbin Top Mount Opening | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Wire Wrap | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder Eyelet(s) | Gold | Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | Right Angle Through Hole | 15 | 15 | Copper Alloy | Single | 1 | Flush Mount Top Opening Unthreaded | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 125 °C | -40 C | 0.156 " | 3.96 mm |
