Switching Power Supplies 400W 5V, 48V U-frame
Switching Power Supplies 400W 5V, 48V U-frame
| Part | Voltage - Input [Max] | Voltage - Input [Min] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Current - Output 1 | Type | Features | Approval Agency | Applications | Efficiency | Voltage - Isolation | Standard Number | Mounting Type | Voltage - Output 1 | Power (Watts) | Number of Outputs | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 2 | Current - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 264 VAC | 90 VAC | 1.6 " | 7.01 in | 4 " | 101.6 mm | 177.8 mm | 40.6 mm | 7.86 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 85 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 28 V | 400 W | 1 | 70 °C | 0 °C | ||
 CUI Inc. | 264 VAC | 90 VAC | 2.15 in | 6 " | 4 " | 101.6 mm | 152.4 mm | 54.5 mm | 9.17 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 87 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 24 V | 400 W | 1 | 70 °C | 0 °C | ||
 CUI Inc. | 264 VAC | 90 VAC | 1.57 " | 6 " | 4 " | 101.6 mm | 152.4 mm | 39.9 mm | 36 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 87 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 5 V | 180 W 320 W | 2 | 70 °C | 0 °C | 24 V | 7.5 A |
CUI Inc. | 264 VAC | 90 VAC | 1.57 " | 6 " | 4 " | 101.6 mm | 152.4 mm | 39.9 mm | 9.17 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 87 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 24 V | 220 W 400 W | 1 | 70 °C | 0 °C | ||
CUI Inc. | 264 VAC | 90 VAC | 2.15 in | 6 " | 4 " | 101.6 mm | 152.4 mm | 54.5 mm | 14.67 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 85 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 15 V | 400 W | 1 | 70 °C | 0 °C | ||
CUI Inc. | 264 VAC | 90 VAC | 1.57 " | 6 " | 4 " | 101.6 mm | 152.4 mm | 39.9 mm | 4.07 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 87 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 54 V | 220 W 400 W | 1 | 70 °C | 0 °C | ||
 CUI Inc. | 264 VAC | 90 VAC | 1.5 in | 6 " | 4 " | 101.6 mm | 152.4 mm | 38.1 mm | 9.17 A | Open Frame | Adjustable Output PFC Remote On/Off Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 85 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 24 V | 220 W 400 W | 1 | 70 °C | 0 °C | ||
CUI Inc. | 264 VAC | 90 VAC | 1.6 " | 7.01 in | 4 " | 101.6 mm | 177.8 mm | 40.6 mm | 4.58 A | Enclosed | Adjustable Output PFC Remote On/Off Standby Output Universal Input | CB Scheme EN IEC SIQ TUV UL | ITE (Commercial) | 87 % | 3000 V | 55024 60950-1 61000-3-2 61000-3-3 62368-1 | Chassis Mount | 48 V | 400 W | 1 | 70 °C | 0 °C |
