E2A-M12 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 8MM CYLIND
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Shielding | Ingress Protection | Indicator | Material - Body | Voltage - Supply [Max] | Voltage - Supply [Min] | Package / Case | Output Type | Sensor Type | Response Frequency | Sensing Distance | Sensing Distance | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | 70 °C | -40 C | Cable Leads | Unshielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire NPN-NC | Inductive | 800 Hz | 8 mm | 0.315 in | |
Omron Automation and Safety | 85 °C | -40 C | Cable Leads | Shielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | PNP-NO | Inductive | 2 mm | 0.079 in | 3 | |
Omron Automation and Safety | 85 °C | -40 C | Connector | Shielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire PNP-NC/NO | Inductive | 1 kHz | 4 mm | 0.157 in | |
 Omron Automation and Safety | 85 °C | -40 C | Connector | Unshielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire NPN-NO | Inductive | 800 Hz | 8 mm | 0.315 in | |
Omron Automation and Safety | 85 °C | -40 C | Cable Leads | Unshielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | PNP-NO | Inductive | 800 Hz | 8 mm | 0.315 in | 3 |
 Omron Automation and Safety | 70 °C | -40 C | Connector | Shielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire PNP-NC/NO | Inductive | 1 kHz | 4 mm | 0.157 in | |
Omron Automation and Safety | 70 °C | -40 C | Connector | Shielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire NPN-NC | Inductive | 1 kHz | 4 mm | 0.157 in | |
 Omron Automation and Safety | 70 °C | -40 C | Connector | Unshielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | PNP-NO | Inductive | 5 mm | 0.197 in | 3 | |
Omron Automation and Safety | 85 °C | -40 C | Cable Leads | Unshielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | 3-Wire NPN-NC | Inductive | 800 Hz | 8 mm | 0.315 in | |
 Omron Automation and Safety | 70 °C | -40 C | Connector | Shielded | IP67 IP69K | LED | Nickel-Plated Brass | 32 VDC | 10 VDC | Cylinder Threaded - M12 | PNP-NO | Inductive | 1 kHz | 4 mm | 0.157 in | 3 |
