25076 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 6COND 16AWG YELLOW 1000'
| Part | Number of Conductors | Conductor Insulation | Length | Length | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Strand [custom] | Conductor Strand [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Ratings | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Cable Type | Conductor Material | Jacket Color | Wire Gauge | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 6 | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | 0.813 mm | 0.032 in | 19 | 0.0117 in | -30 ░C | 90 °C | ISO 10993 UL Style 20668 | Polyurethane (PU) | 8.71 mm | 0.343 in | 300 VDC | Multi-Conductor | Copper Tinned | Yellow | 16 AWG | Biological Compatibility Rip Cord |
 ALPHA WIRE | 6 | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | 0.813 mm | 0.032 in | 19 | 0.0117 in | -30 ░C | 90 °C | ISO 10993 UL Style 20668 | Polyurethane (PU) | 8.71 mm | 0.343 in | 300 VDC | Multi-Conductor | Copper Tinned | Black | 16 AWG | Biological Compatibility Rip Cord |
