DWM-22 Series

Catalog

CONN HDR 22POS 0.05 STACK T/H

Part	Contact Finish Thickness - Post (Mating)	Contact Finish Thickness - Post (Mating)	Color	Pitch [x]	Pitch [x]	Length - Tail [x]	Length - Tail [x]	Length - Post (Mating) [x]	Length - Post (Mating) [x]	Number of Positions	Contact Finish - Post (Mating)	Number of Rows	Mounting Type	Length - Overall Pin	Length - Overall Pin	Termination	Length - Stack Height [x]	Length - Stack Height [x]	Length - Overall Pin [x]	Length - Overall Pin [x]	Row Spacing [x]	Row Spacing	Length - Stack Height [z]	Length - Stack Height [z]
Samtec Inc. DWM-22-58-G-S-397	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	4.775 mm	0.188 in	22 positions	Gold	1	Through Hole	17.907 mm	0.705 in	Solder
Samtec Inc. DWM-22-52-S-S-205	0.76 µm	30 µin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	2.54 mm	0.1 in	22 positions	Gold	1	Through Hole	10.8 mm	0.425 in	Solder	0.205 in	5.207 mm
Samtec Inc. DWM-22-56-G-S-400	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	2.667 mm	0.105 in	22 positions	Gold	1	Through Hole			Solder	0.4 in	10.16 mm	0.625 in	15.875 mm
Samtec Inc. DWM-22-55-G-D-310	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	4.572 mm	0.18 in	44	Gold	2	Through Hole			Solder	0.31 in	7.874 mm	0.61 in	15.494 mm	0.1 in	2.54 mm
Samtec Inc. DWM-22-60-G-D-400	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	7.747 mm	0.305 in	44	Gold	2	Through Hole			Solder	0.4 in	10.16 mm	0.825 in	20.955 mm	0.1 in	2.54 mm
Samtec Inc. DWM-22-52-T-S-220			Black	0.05 in	1.27 mm	0.12 in	3.048 mm	2.159 mm	0.085 in	22 positions	Tin	1	Through Hole	10.8 mm	0.425 in	Solder
Samtec Inc. DWM-22-60-G-D-610	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	2.413 mm	0.095 in	44	Gold	2	Through Hole			Solder			0.825 in	20.955 mm	0.1 in	2.54 mm	0.61 in	15.494 mm
Samtec Inc. DWM-22-53-S-D-265	0.76 µm	30 µin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	3.048 mm	0.12 in	44	Gold	2	Through Hole			Solder	0.265 in	6.731 mm	0.505 in	12.827 mm	0.1 in	2.54 mm
Samtec Inc. DWM-22-60-L-D-530	0.25 Ám	10 Áin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	4.445 mm	0.175 in	44	Gold	2	Through Hole			Solder			0.825 in	20.955 mm	0.1 in	2.54 mm	0.53 in	13.462 mm
Samtec Inc. DWM-22-01-S-D-200	0.76 µm	30 µin	Black	0.05 in	1.27 mm	0.12 in	3.048 mm	3.302 mm	0.13 in	44	Gold	2	Through Hole	11.43 mm	0.45 in	Solder					0.1 in	2.54 mm
