307-080 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 80POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Mounting Type | Color | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Contact Type | Card Type | Card Thickness [Max] | Card Thickness [Min] | Read Out | Termination | Pitch | Pitch | Contact Material | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Gender | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Tin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Female | Tin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Wire Wrap | 3.96 mm | 0.156 in | Copper Alloy | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Female | Gold | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Wire Wrap | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Female | Gold | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Female | Gold | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder Eyelet(s) | 3.96 mm | 0.156 in | Copper Alloy | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Female | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 4-40 Flush Mount Threaded Insert Top Opening | Female | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Female | Gold | 0.25 Ám | 10 Áin | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Female | Tin | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Green | 80 | -40 C | 105 ░C | 2 | Semi Bellows | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Solder Eyelet(s) | 3.96 mm | 0.156 in | Copper Alloy | 40 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Female | Gold | 0.25 Ám | 10 Áin |
