042818 Series
Manufacturer: Molex
Beta
⌘K
CONN PLUG HSG 3POS 10.00MM
| Part | Mounting Type | Note | Contact Termination | Number of Rows | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Color | Pitch [x] | Pitch [x] | Insulation Material | Contact Type | Connector Type | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Panel Mount Snap-In | Contacts Not Included | Crimp | 1 | Locking Ramp | -40 °C | 105 ░C | Black | 0.394 in | 10 mm | Polybutylene Terephthalate (PBT) Polyester | Male Pin | Plug | |
 Molex | Panel Mount Snap-In | Contacts Not Included | Crimp | 1 | Locking Ramp | -40 °C | 105 ░C | Black | 0.394 in | 10 mm | Polybutylene Terephthalate (PBT) Polyester | Male Pin | Plug | 6 |
 Molex | Panel Mount Snap-In | Contacts Not Included | Crimp | 1 | Locking Ramp | -40 °C | 105 ░C | Black | 0.394 in | 10 mm | Polybutylene Terephthalate (PBT) Polyester | Male Pin | Plug | 2 |
 Molex | Panel Mount Snap-In | Contacts Not Included | Crimp | 1 | Locking Ramp | -40 °C | 105 ░C | Black | 0.394 in | 10 mm | Polybutylene Terephthalate (PBT) Polyester | Male Pin | Plug | 4 |
 Molex | Panel Mount Snap-In | Contacts Not Included | Crimp | 1 | Locking Ramp | -40 °C | 105 ░C | Black | 0.394 in | 10 mm | Polybutylene Terephthalate (PBT) Polyester | Male Pin | Plug |
