845-134 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 134POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Color | Termination | Pitch | Pitch | Card Type | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Finish | Number of Positions/Bay/Row | Contact Type | Gender | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Number of Rows [custom] | Read Out | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.25 Ám | 10 Áin | 134 | 2 | Dual | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder Eyelet(s) | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Wire Wrap | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Wire Wrap | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | 67 | Cantilever | Female | 0.25 Ám | 10 Áin | 134 | 2 | Dual | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Gold | 67 | Cantilever | Female | 0.25 Ám | 10 Áin | 134 | 2 | Dual | Card Extender | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Gold | 67 | Cantilever | Female | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | 134 | 2 | Dual | Floating Bobbin Flush Mount | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Gold | 67 | Cantilever | Female | 0.25 Ám | 10 Áin | 134 | 2 | Dual | M3 Threaded Insert Top Mount Opening |
