895-040 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 40POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Card Type | Read Out | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Material | Flange Feature | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Contact Finish | Termination | Number of Rows [custom] | Pitch | Pitch | Color | Gender | Number of Positions | Termination Rows | Number of Positions/Bay/Row [custom] | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | 20 Bay/Row | Gold | Solder | 2 | 0.1 " | 2.54 mm | Black | Female | 40 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | Solder | 0.1 " | 2.54 mm | Black | Female | 40 | 1 | 40 | 1 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Side Mount Opening Unthreaded | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | Solder | 0.1 " | 2.54 mm | Black | Female | 40 | 1 | 40 | 1 | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | 20 Bay/Row | Gold | Solder | 2 | 0.1 " | 2.54 mm | Black | Female | 40 | 0.156 " | 3.96 mm | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | Solder | 0.1 " | 2.54 mm | Black | Female | 40 | 1 | 40 | 1 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | 20 Bay/Row | Gold | Solder | 2 | 0.1 " | 2.54 mm | Black | Female | 40 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | 20 Bay/Row | Gold | Solder | 2 | 0.1 " | 2.54 mm | Black | Female | 40 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | Wire Wrap | 0.1 " | 2.54 mm | Black | Female | 40 | 1 | 40 | 1 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Gold | Wire Wrap | 0.1 " | 2.54 mm | Black | Female | 40 | 1 | 40 | 1 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | 20 Bay/Row | Gold | Solder | 2 | 0.1 " | 2.54 mm | Black | Female | 40 | 0.156 " | 3.96 mm | Card Extender |
