SFV8R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
FFC/FPC CONN
| Part | Mating Cycles | Actuator Color | Housing Color | Current Rating (Amps) | Contact Finish | Locking Feature | Housing Material | Height Above Board [z] | Height Above Board [z] | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Mounting Type | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] | Cable End Type | Flat Flex Type | Material Flammability Rating | Connector/Contact Type | Actuator Material | Termination | Pitch | Pitch | Voltage Rating | Features | FFC, FCB Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | 20 | Brown | Black | 0.5 A | Gold | Slide Lock | Glass Filled Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight | FFC FPC | UL94 V-0 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled | Solder | 0.02 " | 0.5 mm | 50 V | ||
 Amphenol ICC (FCI) | 20 | Black | Black | 0.5 A | Tin | Slide Lock | Glass Filled Halogen Free Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | ||
 Amphenol ICC (FCI) | Brown | Black | 0.5 A | Tin | Slide Lock | Glass Filled Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | ||
 Amphenol ICC (FCI) | 20 | Black | Black | 0.5 A | Tin | Slide Lock | Glass Filled Halogen Free Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | |
Amphenol ICC (FCI) | 20 | Brown | Black | 0.5 A | Tin Alloy | Slide Lock | Glass Filled Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | |
 Amphenol ICC (FCI) | 20 | Beige | Black | 0.5 A | Gold | Slide Lock | Glass Filled Halogen Free Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | Tapered | FPC | UL94 V-0 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | 0.3 mm | |||
 Amphenol ICC (FCI) | Brown | Black | 0.5 A | Tin | Slide Lock | Glass Filled Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | 0.3 mm | 0.33 mm | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | ||
 Amphenol ICC (FCI) | 20 | Beige | Black | 0.5 A | Gold | Slide Lock | Glass Filled Halogen Free Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | 0.3 mm | |||
 Amphenol ICC (FCI) | 20 | Black | Black | 0.5 A | Tin | Flip Lock Slide Lock | Glass Filled Halogen Free Nylon Polyamide (PA) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | Notched Tabbed | FPC | UL94 V-0 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | ||
Amphenol ICC (FCI) | 20 | Black | Black | 0.5 A | Gold | Slide Lock | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 0.071 in | 1.8 mm | Phosphor Bronze | -55 C | 105 ░C | 8 | Right Angle Surface Mount | Straight Tapered | FFC FPC | UL94 V-0 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Solder | 0.02 " | 0.5 mm | 50 V | Solder Retention Zero Insertion Force (ZIF) | 0.33 mm |
