837-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
837 HIGH TEMP' SERIES (.156" (3.
| Part | Material - Insulation | Termination Rows | Color | Contact Type | Termination | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Number of Rows | Pitch | Pitch | Number of Positions | Gender | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Right Angle Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.156 " | 3.96 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | Cantilever | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | 1 | 3.96 mm | 0.156 in | 41 | Female | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 41 | 125 °C | -40 C | Through Hole |
