MRD Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN RCPT MALE 3P GOLD SLDR CUP
| Part | Mounting Feature | Contact Material | Insert Material | Ingress Protection | Connector Type | Mounting Type | Current Rating (Amps) | Primary Material | Orientation | Contact Finish Thickness - Mating | Applications | Shell Material | Shielding | Contact Finish - Mating | Color | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Features | Fastening Type | Backshell Material, Plating | Shell Finish | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Bulkhead - Rear Side Nut | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Panel Mount | 10 A | Plastic | Keyed | Flash | Industrial | Polybutylene Terephthalate (PBT) | Unshielded | Gold | Black | UL94 V-0 | -55 C | 105 ░C | 500 VAC | Dust Cap | Latch Lock | |||
 Amphenol ICC (Commercial Products) | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Receptacle Female Sockets | Free Hanging (In-Line) | 5 A | Plastic | Keyed | Flash | Industrial | Polybutylene Terephthalate (PBT) | Unshielded | Gold | Black | UL94 V-0 | -55 C | 105 ░C | 125 VAC | Backshell | Latch Lock | Polybutylene Terephthalate (PBT) | |||
 Amphenol ICC (Commercial Products) | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Free Hanging (In-Line) | 10 A | Plastic | Keyed | Flash | Industrial | Polybutylene Terephthalate (PBT) | Unshielded | Gold | Black | UL94 V-0 | -55 C | 105 ░C | 500 VAC | Backshell | Latch Lock | Polybutylene Terephthalate (PBT) | |||
 Amphenol ICC (Commercial Products) | Bulkhead - Rear Side Nut | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Panel Mount | 10 A | Metal | Keyed | Flash | Industrial | Zinc Alloy | Unshielded | Gold | Silver | UL94 V-0 | -55 C | 105 ░C | 500 VAC | Dust Cap | Latch Lock | Chrome | 4 | |
 Amphenol ICC (Commercial Products) | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Plug Male Pins | Free Hanging (In-Line) | 5 A | Plastic | Keyed | Flash | Industrial | Polybutylene Terephthalate (PBT) | Unshielded | Gold | Black | UL94 V-0 | -55 C | 105 ░C | 125 VAC | Backshell | Latch Lock | Polybutylene Terephthalate (PBT) | |||
 Amphenol ICC (Commercial Products) | Copper Alloy | Polybutylene Terephthalate (PBT) | IP67 - Dust Tight Waterproof | Plug Female Sockets | Free Hanging (In-Line) | 10 A | Plastic | Keyed | Flash | Industrial | Polybutylene Terephthalate (PBT) | Unshielded | Gold | Black | UL94 V-0 | -55 C | 105 ░C | 500 VAC | Backshell | Latch Lock | Polybutylene Terephthalate (PBT) |
