337-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 27POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Color | Contact Finish | Termination | Number of Rows | Mounting Type | Contact Type | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Read Out | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Gender | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Wire Wrap | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | 27 | Female | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder Eyelet(s) | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | Card Guides | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | 27 | Female | Flush Mount Side Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Wire Wrap | 1 | Right Angle Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | 27 | Female | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Wire Wrap | 1 | Right Angle Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Solder | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 27 | Female | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Gold | Wire Wrap | 1 | Through Hole | Cantilever | Non Specified - Single Edge | -40 C | 105 ░C | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 2.95 mm | 0.116 " | 27 | Female | Floating Bobbin Flush Mount |
